Automatic Hydraulic Pipe Bending Machine Line Hot Tube Bender Elbow Making Production Line

Certification : ISO9001:2015/CE

After-sales Service Provided : Engineers available to service machinery overseas

Delivery Time : 60 days

Bending Type : Pipe, Square tube, Rectangle tube, Beam

Material : Carbon steel, stainless steel, alloy

Place of Origin : Sichuan, China

Application : Hot bending

Brand Name : Duolin pipe induction heating machine

core components : PLC

MOQ : 1

Diameter range : 168mm-762mm

Contact Now

Automatic Hydraulic Pipe Bending Machine Line Hot Tube Bender Elbow Making Production Line

Installed in Nigeria Hydraulic Induction Pipe Bending Machine Big Bending Radius Hot Bender

Tube & Pipe Induction Heating Machine for Bending
Automatic Hydraulic Pipe Bending Machine Line Hot Tube Bender Elbow Making Production Line

Hydraulic hot pipe section bending machine is complete tube induction bending equipment for producing hot bends and elbows. Low frequency induction power supply heats the pipe with heating coil to reach temperature around 1000°C. The hydraulic bending machine pushes the pipe and forms different radii and angle hot bends simultaneously.

This advanced pipe bending process offers high speed and efficiency, improving final product quality with less distortion and wall thinning compared with cold and traditional pipe bending methods.

Applications
  • Roadway signage
  • Construction (structural shapes)
  • Pipeline for oil & gas (on and offshore)
  • Hot water pipes
  • Pipeline for chemical raw material
  • Pipeline for electric wires
Automatic Hydraulic Pipe Bending Machine Line Hot Tube Bender Elbow Making Production Line
Induction Bending Machine Specifications
  • Bending pipe: Diameter 60mm-2000mm, wall thickness 2-120mm
  • Power output: 100-1500KW
  • Bending Type: Pipe, Square tube, Rectangle tube, Beam
  • Material: Carbon steel, stainless steel, alloy steel
  • Bending speed: Around 2.5 mm per minute according to pipe dimension
  • Bending angle: 0-180° or set any angle
  • Bending Radius: 3D ≤ R ≤ 10D
  • Pipe length: Up to 18 meter
Induction Bending Machine CAPACITY MAX O.D. (mm) x Wall (mm)
Induction Bending Machine 168 168 x 13
Induction Bending Machine 325 325 x 25
Induction Bending Machine 426 426 x 30
Induction Bending Machine 530 530 x 30
Induction Bending Machine 630 630 x 30
Induction Bending Machine 720 720 x 35
Induction Bending Machine 810 813 x 35
Key Features
Maintains constant heating temperature during bending, ensuring physical characteristics of bends or elbows
Power factor not less than 0.95
Precise heating and bending for better quality bends and cost savings
Capable of bending square tubes, rectangular tubes, and angle steel
Low installation and operation cost
No sand filling or internal mandrels required
Superior quality at ovality and wall thinning
PLC control to set and store each pipe bending process parameter
Faster and more energy efficient than traditional fire/hot slab bending methods
Compatible with both seamless and welded tubes & pipes
Heating temperature controlled by PLC with bending process recording for repeat bending
Application Cases
Automatic Hydraulic Pipe Bending Machine Line Hot Tube Bender Elbow Making Production Line Automatic Hydraulic Pipe Bending Machine Line Hot Tube Bender Elbow Making Production Line
Our Services
Automatic Hydraulic Pipe Bending Machine Line Hot Tube Bender Elbow Making Production Line
Company Information
Automatic Hydraulic Pipe Bending Machine Line Hot Tube Bender Elbow Making Production Line Automatic Hydraulic Pipe Bending Machine Line Hot Tube Bender Elbow Making Production Line
Frequently Asked Questions
What we need to know before offering pipe hot bender solution?
  • The pipe material, length, wall thickness and OD
  • Bending radius and angle
  • For elbow or hot bender application
  • Bending production requirements
  • The usage of pipe (for gas, oil or other industry)
  • Requirements for ovality and wall thinning
  • Bending pipe length specifications
Other applications for Induction pipe heating:
  • Induction pipe coating for anticorrosive protection
  • Induction heating for pipe expansion
  • Pipe ends heating for hot forging processes
Automatic Hydraulic Pipe Bending Machine Line Hot Tube Bender Elbow Making Production Line Automatic Hydraulic Pipe Bending Machine Line Hot Tube Bender Elbow Making Production Line
